Perplex.ContentBlocks

Block based content editor for Umbraco.

This package works on top of NestedContent but provides a more advanced user interface and adds some new features:

Release Notes

Release notes are available here.

Umbraco 14+

Umbraco 14+ no longer supports Nested Content and the Backoffice is completely rewritten using Web Components instead of AngularJS. As a result, all current versions of Perplex.ContentBlocks do not work in Umbraco 14.

The next major version of ContentBlocks - v4 - will transition from Nested Content as the underlying data storage to Umbraco's Block Editor technology which is used in Block List + Block Grid. In addition we will migrate the property editor UI in the Backoffice from AngularJS to Web Components. ContentBlocks v4 will no longer support Umbraco v10-v13.

We intend to release v4 at the end of this year, around the same time as Umbraco v15. This timeline is still subject to change.

Because Umbraco is planning to introduce Block Level Variations in v15 which requires breaking changes to the Block data structure and other Block related code it is possible ContentBlocks v4 will target Umbraco v15+, skipping v14 entirely. The current (unstable) state of v14 contributes to this idea too as it is unlikely many companies want to use v14 in production at the moment.

ContentBlocks v4 will automatically migrate property data of ContentBlocks v1 - v3 to v4. This is necessary for any websites that upgrade from Umbraco 8-13 to 14+ and have existing ContentBlocks property data. This data needs to be migrated from the Nested Content format to the new Block Editor format. Both editors use Element Types which means the actual property data is the same but they use a different wrapper structure around it so that will have to be migrated.

Until ContentBlocks v4 is out Umbraco 14 is not supported.

Umbraco 10+ / .NET 6+

ContentBlocks v3 supports the following Umbraco versions:

It can be installed as usual via NuGet:

dotnet add package Perplex.ContentBlocks

For older versions of Umbraco, use v1 or v2.

v3 is backwards compatible with v2 and contains no breaking changes except it no longer supports .NET Framework / Umbraco 8. It adds support for using View Components to render blocks and static files (App_Plugins\Perplex.ContentBlocks) are now distributed as part of a Razor Class library (Perplex.ContentBlocks.StaticAssets).

When upgrading from v2, make sure to remove the physical App_Plugins\Perplex.ContentBlocks folder from your project. The v3 static assets will be loaded from the RCL without being on disk in your project during development.

Demo

A short demo video can be viewed below.

Watch on Vimeo

Installation

The package can be installed using NuGet:

dotnet add package Perplex.ContentBlocks

Quick Start

To start in the quickest way without writing any code, copy the code below to a new file in your project (e.g. Example.cs), then compile it and run your site.

If you do not have Visual Studio or another tool to compile code, you can save the code to a .cs file in App_Code in the root of your project, which should compile it on the fly. If the folder does not exist yet simply create it.

For a more detailed explanation and step-by-step guide, head over to Getting Started.


This code will:

  1. Create a Document Type "Example Block" with the alias "exampleBlock" and two properties "Title" (text) and "Text" (rich text editor)
  2. Create a NestedContent data type for it called "Perplex.Contentblocks - ExampleBlock"
  3. Configure a Header and a Block to use the data type

What you now can do in your solution is:

  1. Create a new data type based on the Perplex.ContentBlocks property editor. Call it "Perplex Contentblocks"

perplex contentblocks

  1. Add this property to a document type of your choice

    Add to document type

  2. You should now be able to pick blocks on a content page of the document type.

Contentpage

Also note this does not cover the front-end rendering yet, so nothing will happen there yet. Head over to the Rendering Content Blocks section for an explanation about that.

Getting Started

In order to use this package, you will need to configure at least 1 Content Block.

After that is done, you can add the data type Perplex.ContentBlocks as a property to any document type where you want to use this content editor.

Because ContentBlocks is built on top of Nested Content, creating a block starts out the same as creating a new Nested Content data type. After that, there is a little bit of extra work to make the Nested Content data type work as a block within ContentBlocks.

In short, the steps to configure a Content Block are:

  1. Create a document type

    • Add any properties you need for the Content Block
    • Tick "Is an element type" in Permissions

  2. Create a data type based on Nested Content

    • Select the document type created in step 1
    • Set min. items and max. items to 1
    • Hide the label

  3. Describe the Content Block using an implementation of the IContentBlockDefinition interface.

  4. Add the definition created in step 3 to an IContentBlockRepository

    • Either use the built-in repository:

      // Inject
IContentBlockDefinitionRepository definitions;

// Your definition
var definition = new ContentBlockDefinition { /* ... */ };

// Add to the repository
definitions.Add(definition);

    • Or register your own implementation in a composer and register it there:

      composition.RegisterUnique<IContentBlockDefinitionRepository, MyDefinitionRepository>();
      • Make sure your composer runs after the ContentBlockDefinitionComposer.

Content Block Definition

The definition of a Content Block consists of the following properties:

Content Block Layout

Each Content Block has at least 1 layout. This refers to the view that will be rendered. It is possible to define multiple layouts per block. The user will be able to switch layouts from Umbraco. A layout is described using an implementation of IContentBlockLayout, which has the following properties:

Content Block Categories

Content Blocks are organized in categories and presented that way to the user. The categories are retrieved from a registered IContentBlockCategoryRepository. By default, this package contains two categories: "Headers" and "Content". Their ids are available as constants in Perplex.ContentBlocks.Constants.Categories. You can manipulate these categories by either:

OR

Rendering Content Blocks

To render all Content Blocks from the page containing the blocks, you can either use the IContentBlockRenderer directly, or call an extension method with the Content Blocks model value (of type IContentBlocks). In v3 we added a tag helper for rendering.

The examples assume the property alias of the Perplex.ContentBlocks property is "contentBlocks" which translates to a ModelsBuilder property of ContentBlocks. In both cases we run the example code in the Razor view file of the document type that contains the Content Blocks (e.g. Homepage.cshtml):

  1. Using the tag helper (v3+):

Ensure the Tag Helper is imported in your views by adding it to _ViewImports.cshtml:

@addTagHelper *, Perplex.ContentBlocks

// All blocks (header + blocks):
<perplex-content-blocks content="Model.ContentBlocks" />

// A single block (e.g. header only)
<perplex-content-blocks block="Model.ContentBlocks.Header" />

// Multiple blocks (e.g. all blocks except header)
<perplex-content-blocks blocks="Model.ContentBlocks.Blocks" />
  1. Using the extension method (deprecated in v3 as it does not support rendering view components):
// ContentBlocks v2 - Umbraco v8
@using Perplex.ContentBlocks.Rendering;
@Html.RenderContentBlocks(Model.ContentBlocks)

// ContentBlocks v2 - Umbraco v9+
@using Perplex.ContentBlocks.Rendering;
@inject IContentBlockRenderer Renderer
@await Html.RenderContentBlocks(Model.ContentBlocks, Renderer)
  1. Using the renderer:
// Umbraco v8
@{
    // Inject
    IContentBlockRenderer renderer;
}
@renderer.Render(Model.ContentBlocks, Html)

// Umbraco v9+
@inject IContentBlockRenderer Renderer
@await Renderer.Render(Model.ContentBlocks, Html.PartialAsync)

// ContentBlocks v3+
@inject IContentBlocksRenderer Renderer
@await Renderer.RenderAsync(Model.Content.ContentBlocks, Component.InvokeAsync, Html.PartialAsync)

Rendering a Content Block

The renderer will render each Content Block by using their configured View and pass in a generic IContentBlockViewModel<TContent> where TContent is the ModelsBuilder type of the content.

Because this TContent is a ModelsBuilder model, you can either use strongly typed properties or the .Value() method to render its properties.

An example Content Block view file for a Content Block with document type alias "exampleBlock" and ModelsBuilder model ExampleBlock will look something like this:

@using Perplex.ContentBlocks.Rendering;
@model IContentBlockViewModel<ExampleBlock>
<h1>@Model.Content.Title</h1>
<img src="https://github.com/PerplexDigital/Perplex.ContentBlocks/raw/master/@Model.Content.Image.Url" />

The Model.Content property is the IPublishedElement of the Content Block content and rendering them is the same as rendering any Umbraco content in the front-end.

Advanced

Render Blocks using View Components

Starting with ContentBlocks v3 you can use IContentBlockDefinition<T> where T is a ViewComponent. When rendering your block, this ViewComponent will be called with a IContentBlockViewModel<TModel> parameter. This is useful if you want to use custom logic or a custom view model to render your blocks.

For example, with a ContentBlock definition like this:

new ContentBlockDefinition<SampleBlockViewComponent> // Note the <SampleBlockViewComponent>
{
    Name = "Sample Block",
    Id = new Guid("..."),
    DataTypeKey = new Guid("..."),
    Layouts = new []
    {
        new ContentBlockLayout
        {
            Id = new Guid("..."),
            Name = "Default",
            PreviewImage = "...",
            ViewPath = "..." // Optional when using ViewComponents
        },
    }
};

You can use a ViewComponent to render this block like this:

public class SampleBlockViewComponent : ViewComponent
{
    private readonly ISomeService _someService; // Some service required for your use case
    public SampleBlockViewComponent(ISomeService someService) => _someService = someService;

    public async Task<IViewComponentResult> InvokeAsync(IContentBlockViewModel<SampleBlock> model)
    {
        var someValue = await _someService.GetValueAsync();
        var viewModel = new SampleBlockViewModel(model, someValue);
        return View("/Path/To/SampleBlock_View.cshtml", viewModel);
    }

    // Or the sync version:
    // public IViewComponentResult Invoke(IContentBlockViewModel<SampleBlock> model)
    // {
    //     var someValue = _someService.GetValue();
    //     var viewModel = new SampleBlockViewModel(model, someValue);
    //     return View("/Path/To/SampleBlock_View.cshtml", viewModel);
    // }
}

Custom View Model

Sometimes you need a more complex view model than just the IContentBlockViewModel<TContent>. In this case, you can register a custom view model factory that will generate your custom view model for you.

Note that starting with v3 you can use View Components to render your blocks which is the recommended approach instead of the ViewModelFactory approach described in this section.

For example, if you have the ContentBlock ExampleBlock and instead of the default IContentBlockViewModel<TContent> you want some custom view model ExampleBlockViewModel, this is what you do:

  1. Create your View Model with some additional properties.
    • This custom view model should implement IContentBlockViewModel
    • The example below inherits from the built-in class ContentBlockViewModel<TContent>, this is the easiest way
    • Note the IEnvironment we add to the view model is only an example. Likewise, we inject some IEnvironmentProvider to obtain that IEnvironment which is also an example to show how you would inject your own classes.
public class ExampleBlockViewModel : ContentBlockViewModel<ExampleBlock>
{
    // In this example we add some "IEnvironment" property to our view model.
    // Note this is just an example, there is no need to include this property on your
    // custom view model to make it work.
    public IEnvironment Environment { get; }

    public ExampleBlockViewModel(ExampleBlock content, Guid id, Guid definitionId, Guid layoutId,
        IEnvironmentProvider environmentProvider)
        : base(content, id, definitionId, layoutId)
    {
        Environment = environmentProvider.GetEnvironment();
    }
}
  1. Create a View Model factory that is used to create this view model:
    • This factory should implement IContentBlockViewModelFactory<TContent>.
    • The easiest way is to inherit from ContentBlockViewModelFactory<TContent> like we do below, and override its Create method.
public class ExampleBlockViewModelFactory : ContentBlockViewModelFactory<ExampleBlock>
{
    private readonly IEnvironmentProvider _environmentProvider;

    // Inject the required dependencies into the factory.
    // Note the "IEnvironmentProvider" is just an example,
    // you want to inject your own dependencies here.
    public ExampleBlockViewModelFactory(IEnvironmentProvider environmentProvider)
    {
        _environmentProvider = environmentProvider;
    }

    public override IContentBlockViewModel<ExampleBlock> Create(
        ExampleBlock content, Guid id, Guid definitionId, Guid layoutId)
    {
        // Pass dependencies to the ExampleBlockViewModel constructor,
        // we pass our IEnvironmentProvider in this example but
        // you want to pass your own dependencies instead.
        return new ExampleBlockViewModel(content, id, definitionId, layoutId, _environmentProvider);
    }
}
  1. Register your view model factory in some IUserComposer:
composition.Register(
    typeof(IContentBlockViewModelFactory<ExampleBlock>),
    typeof(ExampleBlockViewModelFactory),
    Lifetime.Scope);
  1. Use the view model in your view (ExampleBlock.cshtml):
@model ExampleBlockViewModel

@if(Model.Environment.IsDevelopment()) {
    @RenderDebugInfo()
}

@* Other properties as usual *@
<h1>@Model.Content.Title</h1>

Content Block Presets

It is possible to define a "Preset", which is a predefined selection of Header + Blocks to be pre-filled when a page does not have any blocks yet.

Presets implement the interface IContentBlocksPreset and should be added to an IContentBlocksPresetRepository.

An IContentBlocksPreset has the following properties:

Preset initial property values

Starting from version 1.8.0 it is possible to provide initial property values for an IContentBlockPreset using its Values property which is an IDictionary<string, object>. Usage:

new ContentBlockPreset
{
    Id = ...,
    DefinitionId = ...,
    LayoutId = ...,
    Values =
    {
        // For example, to set the initial values for properties "title" and "text":
        ["title"] = "Default title here",
        ["text"] = "<p>Lorem ipsum ...</p>"
    },
},

Creating Content Blocks programmatically

There are no specialized APIs in our package to create Content Blocks through code but you can use Umbraco's IContentService and use SetValue() to set a ContentBlocks property value. The value should be a JSON string and the structure is shown below. The main task is generating that "Nested Content data" part.

{
    /* version can change in the future if the model value structure changes, but that is unlikely */
    "version": 2,
    "header": {
        "id": "...",
        "definitionId": "...",
        "layoutId": "...",
        "presetId": null,
        "isDisabled": false,
        "content": [
            {
                /* Nested Content data */
            }
        ]
    },

    "blocks": [
        /* Same format as header */
    ]
}
